| CPU |
Intel® Celeron® N5095 4-core/4-thread processor, burst up to 2.9 GHz |
| CPU Architecture |
64-bit x86 |
| Graphic Processors |
Intel® UHD Graphics |
| Floating Point Unit |
|
| Encryption Engine |
(AES-NI) |
| Hardware-accelerated Transcoding |
|
| System Memory |
8 GB RAM |
| Maximum Memory |
8 GB |
| Flash Memory |
5GB (Dual boot OS protection) |
| Drive Bay |
3 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility |
3.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
An optional 2.5" drive tray base (TRAY-25-NK-BLK03) is needed to install a 2.5" SSD/HDD
|
| Hot-swappable |
|
| M.2 Slot |
2 x M.2 2280 PCIe Gen 3 x2 slots
|
| SSD Cache Acceleration Support |
|
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
1(2.5G/1G/100M) |
| Wake on LAN (WOL) |
|
| Jumbo Frame |
|
| USB 3.2 Gen 1 port |
1 |
| USB 3.2 Gen 2 (10Gbps) Port |
2 x Type-A |
| HDMI™ Output |
1, HDMI™ 1.4b (up to 4096 x 2160 @ 30Hz) |
| Form Factor |
Tower |
| LED Indicators |
System Status, LAN, USB, HDD1~3, M.2 SSD1~2 |
| Buttons |
Power, Reset, USB Copy |
| Dimensions (HxWxD) |
5.75 x 5.59 x 10.12 inch Dimensions do not include foot pad (foot
pad may be up to 30mm / 1.18 inches high depending on model)
|
| Weight (Net) |
5.73 lbs |
| Weight (Gross) |
6.61 lbs |
| Operating Temperature |
0 - 40 °C (32°F - 104°F) |
| Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
| Power Supply Unit |
65W adapter, 100 - 240V |
| Power Consumption: HDD Sleep Mode |
18.9 W |
| Power Consumption: Operating Mode, Typical |
32.8 W Tested with drives fully populated.
|
| Fan |
1 x 92mm, 12VDC |
| System Warning |
Buzzer |
| Kensington Security Slot |
|
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory |
1500 |
