ACTI Q450 - 8MP Multi-Imager 180 Degree Bullet with D/N, Adaptive IR, Superior WDR, SLLS, 2 Fixed lenses
by ACTi
|
|
|
|
- 8 Megapixel
- Day & Night with Superior Low Light Sensitivity and Adaptive IR LED
- Fixed Lens with f2.8mm/F1.6
- Superior WDR
- H.265 Compression
- Super wide angle
- Event trigger, response and notification
|
|
|
8MP Multi-Imager Panoramic Bullet with D/N, Adaptive IR, Superior WDR, SLLS, 2 Fixed lenses, f2.8mm (HOV:180°), H.265/H.264, Dewarping
Device
| Product Type |
Multi-Imager 180 Degree Bullet |
| Maximum Resolution |
8MP |
| Application Environment |
Outdoor |
| Image Sensor |
Progressive Scan CMOS |
| Sensor Size |
1/1.8 " |
| Effective Pixels |
2704(H) X 1568(V) (4 MP) |
| Day / Night |
Yes |
| Low Light Sensitivity |
Superior |
| Mechanical IR Cut Filter |
Yes |
| IR LED |
Adaptive IR LED |
| IR Working Distance |
40m |
Lens
| Number of Lenses |
2 Lenses |
| Focal Length |
Fixed focal, f2.8mm |
| Aperture |
F1.6 |
| Horizontal Viewing Angle |
180° |
Video
| Compression |
H.265, H.264, MJPEG |
| Maximum Frame Rate vs. Resolution |
30 fps at 5120 x 1440 |
| Multi-Streaming |
Simultaneous quad streams |
| Wide Dynamic Range |
Superior WDR (120 dB) |
| Digital Noise Reduction |
2D + 3D DNR |
| Video Stitching |
Seamless Video Stitching
Minimum Stitching Distance: 450 cm |
Audio
| Audio Type |
2-way, Line-in, Line-out |
Network
| Network Protocol & Service |
IPv4/v6, ARP, ICMP, IGMP, PPPoE, QoS, TCP, UDP, DHCP, UPnP, SNMP, SMTP, RTP, RTSP, HTTP, HTTPS, FTP, NTP, DDNS, IEEE 802.1X |
| Ethernet Port |
1 x Ethernet (1000 Base-T), RJ-45 connector |
| Security |
Password protected user level, IP address filtering, HTTPS encryption, IEEE 802.1X network access control |
Event
| Event Trigger |
Video motion detection, Tampering detection, Sound detection, External device through digital input, |
| Event Response |
Send E-mail Notification, Save video to local storage, Upload snapshot to FTP server, Activate external device through digital output |
Integration
| ONVIF Compliant |
Yes, Profile S, Profile G, Profile T |
Interface
| Audio Interface |
1/1, 3.5mm Phone Jack |
| Local Storage |
MicroSD, MicroSDHC, MicroSDXC memory card slot (card not included) |
| Digital Input/Output |
2/1 (Terminal block) |
General
| Power Source |
AC 24V, PoE (IEEE802.3af) |
| Dimensions |
(Ø x L): 140mm x 105.5mm (5.51" x 4.15") |
| Environmental Casing |
Weatherproof (IP66), Vandal proof metal casing (IK10) |
| Operating Temperature |
-40°C ~ 55°C (-40°F ~ 131°F) |
| Operating Humidity |
10% - 90% RH |
| Approvals |
CE Class A, FCC Class A, LVD, IP66, IK10 (metal casing) |
| Material |
Metal
Plastic |
|
|
