| JBOD Connection Interface |
SAS |
| Drive Bay |
16 x 3.5-inch
|
| Drive Compatibility |
3.5-inch bays:
3.5-inch SAS 12Gb/s, 6Gb/s hard disk drives
2.5-inch SAS 12Gb/s,
6Gb/s hard disk drives
2.5-inch SAS 12Gb/s, 6Gb/s solid state drives You can
only use one disk type (HDD or SSD) in a RAID group. Combining different types of disk in one RAID
group is not supported.
|
| Hot-swappable |
|
| Form Factor |
3U Rackmount |
| Host Interface |
3 x 12Gb/s SAS 3.0 wide ports (4-wide port) Mini-SAS HD (SFF-8644) for each controller
|
| LED Indicators |
HDD 1-16, Status, Power, Fan, Temperature, SAS connector status |
| Buttons |
Power, OLED |
| Dimensions (HxWxD) |
5.17 x 18.98 x 16.74 inch Excludes ear hook and the
protruding part of the Power Supply Unit.
|
| Weight (Net) |
30.69 lbs |
| Weight (Gross) |
39.33 lbs |
| Operating Temperature |
0 - 40 °C (32°F - 104°F) |
| Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
| Power Supply Unit |
550W(x2), 100-240V |
| Power Consumption: Operating Mode, Typical |
212.24 W Tested with drives fully populated.
|
| Fan |
3 x 80mm, 12VDC |
| System Warning |
Buzzer |
| QES |
|
| Windows |
|
| Supports JBOD cascading |
|
| Supports expanding NAS storage pools |
|
| Supports Multi-path |
|
| Dual-controller design (HA) |
|
| Management |
Managed via NAS QES OS and JBOD Manager for Windows |
